The Ultimate Dry Waste Management Solution: HPVR-1000 PDB Vacuum Truck

Designed to excel in handling dry waste like power station ash, cement dust, and sandblast waste, the HPVR-1000 PDB Vacuum Truck is a powerhouse of efficiency and reliability. Built with innovative features and engineered to withstand demanding environments, it is an indispensable asset for industries managing bulk dry materials. Whether you’re dealing with power station ash or other challenging dry waste, this vacuum truck delivers unparalleled performance.

Optimized for Peak Performance

The HPVR-1000 PDB is equipped with a cutting-edge 52-bag filtration system that ensures consistent, hassle-free operation. Here’s what makes it stand out:

  • Automatic Airflow Monitoring: The system continuously tracks airflow levels, alerting operators to potential issues.
  • Self-Cleaning Filters: When dust builds up, the automatic cleaning mechanism activates, restoring optimal performance with minimal downtime.
  • Operator Control Panel: Operators can easily monitor and manually pulse the filters when needed, providing full control over the system.

These features make the HPVR-1000 PDB a reliable, high-performance solution for even the toughest dry waste management tasks.

Built for Tough Jobs and Long-Term Durability

Durability is at the core of the HPVR-1000 PDB’s design. By manufacturing nearly all components in-house, we ensure:

  • Quick Repairs: Replacement parts are readily available, reducing delays.
  • Enhanced Reliability: Strict quality control means every part meets high standards.
  • Cost Savings: Lower dependence on external suppliers translates to greater value for our customers.

This commitment to quality and reliability means the HPVR-1000 PDB is a smart investment for any business needing robust waste management solutions.

Tackling Industry Challenges with Confidence

Handling dry waste like cement dust and ash requires specialized equipment. The HPVR-1000 PDB is engineered to meet these challenges head-on, offering:

  • High Capacity: Handle large volumes of dry waste efficiently.
  • Versatility: Suitable for a wide range of materials, from sandblast waste to bulk dry debris.
  • Precision Engineering: Every feature is optimized to deliver consistent, powerful performance.

Why Choose the HPVR-1000 PDB?

Selecting the right vacuum truck is about more than just technical specifications—it’s about finding a dependable, efficient partner for your operations. The HPVR-1000 PDB offers:

  • Efficiency: Automatic cleaning reduces manual intervention, saving time and labor.
  • Reliability: In-house manufacturing minimizes downtime.
  • Ease of Use: The user-friendly interface simplifies operation and monitoring.
  • Proven Results: Built specifically for the waste management industry, the HPVR-1000 PDB delivers outstanding outcomes.

Your Next Step in Waste Management

The HPVR-1000 PDB is more than a vacuum truck—it’s a long-term solution for optimizing your waste management operations. By choosing this robust and efficient system, you’re investing in a tool designed to adapt to your needs and deliver consistent results.

Ready to transform your operations? Contact us today to learn more about the HPVR-1000 PDB Vacuum Truck and discover how it can take your business to the next level.

Material316L Stainless Steel
Thickness6 mm
Ends6 % Toro-spherical Ends
ReinforcementExternal Rolled Rings
Max Pressure10 Bar
Spillage PreventionSpillage Chute
Spillage PreventionPneumatic Isolation Valve
Inlet Port ProtectionMaterial Deflector
Vacuum Capacity12 500 L
Tank Access PointManway (500mm)
Tank Overflow ProtectionPrimary Shutoff Valve
Pressure Relieve ValveYes
Rupture Protection DiscYes
Water CapacityN/A
Low Level Cut Out SensorN/A
Water Surge ProtectionN/A
Filling PortN/A
Tipping Capacity14 Ton
Tipping Angle50 Degrees
Tank RealignmentSelf Aligning, Tie in system
Burst Valve ProtectionYes
Door Opening and ClosingFully Hydraulic
Door HingesHeavy duty, adjustable door hinges
Door Locking System6 Hydraulic locking clamps
Suction PortDN150 PN15 Ball Valve
Discharge PortDN150 PN15 Ball Valve
Level IndicatorSwing Arm Ball Float
Door SealHeavy duty EPDM, wear resistant door seal
Flow Rate30 lpm
Oil Tank Capacity70 L
Filtration Stage 1Heavy Duty, Twin Cyclone + Knock Out Boxes
Filtration Stage 2Stainless steel mesh strainer
Filtration Stage 352 Bag Filter (127 mm x 1200 mm)
Filtration Stage 4Pulsating Bag Cleaner
Filtration Stage 5N/A
EngineSplit shaft
Fuel Tank CapacityN/A
Output Power130 kW dual output
Output Torque1960 Nm
Drive Through Torque25 kN (35 kN intermittent)
Gear Ratio1:1.26
Belts and Pulley SystemSelf tensioning
TypeJurop PVT Tri-Lobe
Flow Rate3980 m3/h, Free Flow
Pressure-90 kPa
Non-Return ValveYes
Tank CapacityN/A
ThicknessN/A
MaterialN/A
Access PointN/A
Filling PortN/A
Drain ValveN/A
TypeN/A
Flow RateN/A
PressureN/A
Adjustable By Pass ValveN/A
Pneumatic Actuated Three Way Diverter ValveN/A
OperationN/A
ExtentionN/A
Slew MovementN/A
SizeN/A
OperationN/A
SizeN/A
LengthN/A
Max LengthN/A
Max PressureN/A
MudgaurdsHigh Durability Steel and Rubber
Hose Tray Storage1x Full Length, 3CR12 Stainless Steel
Tool Boxes1x Full Length, 3CR12 Stainless Steel
Muck BoxesMild Steel Boxes
Wash Down GunOptional
Walkway With Non-SlipFull Length, Non-slip
Access LadderNon-Slip, Corrosion Resistant
Wireless RemoteOptional
Saddle Water TanksN/A
Signage BoardsN/A
Hoses Included
Revolving Emergency Light2x Amber Revolving Light
Warning DecalsYes
Static Earthing Cable8 mm, 10 meters long
Harness Attachement Points On WalkwayYes
Unattended Lock-Out SystemYes
PTO Lock-Out System While DrivingYes
Pneumatic In-Cab PTO On/Off SwitchYes
Fast Reacting Emergency StopYes
Detailed Component DecalsYes
NDT (Non-Destructive-Testing)Yes
X-ray Inspection10% of welds
Pressure TestWater Fill Test (1,4 Bar)
Operators ManualIncluded
Maintenance ManualIncluded
Homologated For Use In SAYes
Hazard Board HolderYes
Underrunner BumperSABS Approved, Chevron and Lights

Request A Quote

Name(Required)

The Vacuum Pump System

The HPVR-1000 PDB, equipped with a robust Jurop Vacuum pump, ensures reliable performance and long life. Featuring advanced overheating protection, this low-maintenance pump operates quietly and efficiently, delivering a flow rate of 4150 m³/h at 0% vacuum. A stainless steel mesh strainer safeguards the pump, while a one-way valve guarantees uni-directional flow.

HPVR 1000 PDB Vacuum Truck 008

The Filter System

The HPVR-1000 PDB features a 52-bag filtration system with automatic airflow monitoring and cleaning. It maintains optimal performance by detecting airflow issues and using pulsed air to clear dust buildup. Operators can also manually control cleaning via a user-friendly screen, ensuring reliable and efficient operation in demanding environments.

HPVR 1000 PDB Vacuum Truck 007
